10KG Composite LPG Cylinder

EN12245 standard 10kg lpg cylinder fiberglass gas cylinder lpg tank plastic composite lpg cylinder

Corrosion resistance, impact resistance, high strength, high toughness, weather resistance, high temperature resistance, flame retardant and other characteristics.The inner liner is a non-load bearing LPG container with a certain rigidity,and can be used as a mold for filament winding.It is required that the wall thickness of inner should be controlled evenly, impact toughness resistance,and no creep failure or stress cracking during the service life.Good air tightness, corrosion resistance and high temperature resistance.



Share:
10KG Composite LPG Cylinder
Description:
Corrosion resistance, impact resistance, high strength, high toughness, weather resistance, high temperature resistance, flame retardant and other characteristics.
The inner liner is a non-load bearing LPG container with a certain rigidity,and can be used as a mold for filament winding.
It is required that the wall thickness of inner should be controlled evenly, impact toughness resistance,and no creep failure or stress cracking during the service life.Good air tightness, corrosion resistance and high temperature resistance.
Features:
1.Anti-rust
2.Anti-corrosion
3.Pressure reach 70 kg
4.Transparent cylinder bottle body
5.No explosion in high temperature
6.Lightweight 8kg
7.Service life is 15 years guaranteed
8.Enterprise self-inspection,no need supervise from the third party

Technology specification:
Composite LPG cylinder 24.5L
Propane capacity(kg) 10kg
Butane capacity(kg) 12kg
Water content(L) 24.5L
Over all Length(mm) 570mm
Diameter(mm) 307mm
Service Pressure(Bar) 20bar
Test Pressure(Bar) 30bar
Material: HDPE+glass fiber
Thread Specification: 25E
Stabdard: ISO11119-3/EN12245
MOQ:1180







Portable new material HDPE wrapped fiberglass composite plastic LPG gas cylinder
Benefits of composite LPG cylinders:
1.Light weight
2.Transparency
3.Hight quality
4.Explosion safe
5.Corrosion free and ultra-violet radiation proof
6.Explosion-proof under fire exposure and impact load
7. Transportation costs will be lowered due to the reduced weight
8.An even tare weight removes the need to adjust the filling machines for each cylinder,thereby saving man hours
The ultimate goal is to produce a high quality,"safety first" factory and products that are approved by international government agencies for containment and transportation of LPG.
Quick Details
Pressure: High
Place of Origin: Anhui
Model Number: LPG--24.5L
Material: Composite Material
Brand Name: LD
Use: LPG
Working Pressure: 20 Bar
Hyd.Test Pressure: 30bar
Diameter: 321mm
Water Capacity: 24.5L
Height: 570mm±5mm
Weight: 6.5kg
Thread: 3/4''-14NGT,25E/M26X1.5
Filling Medium: lpg,propane,Butane
Standard: EN12245/ISO 1119-3
